Replacement PARKER High Flow Filter Cartridges

PARKER high flow filter cartridge is a replacement cartridge for the depth filtration and other 2-1/2" diameter cartridges for the high flow applications, such as reverse osmosis pre-filtration and similar applications that nominal efficiency can meet corresponding requirements. The flow rate of each filter cartridge is as high as 1300 liters per minute, which significantly reduce the number of filter cartridges and housing dimensions. The treatment capacity of a PARKER filter cartridge is equivalent to that of 10 filter cartridges with an outer diameter of 2-1/2" and a length of 40".

Product Specifications

Product Detail

Product name:	PARKER high flow filter cartridge
Filter Media	Polypropylene Pleated
Length	30″, 40″
Outside Diameter	6 inch(152mm)
Filtration Rating	0.5μm, 1μm, 5μm, 10μm, 20μm
Support/Drainage	Polypropylene (PP)
End Cap Material	Polypropylene (PP), 226 O-Ring/Flat Cap with handle
Seal Material	EPDM, Buna-N, Viton, Silicone
Outside	Netting

Interested in larger quantities?

Request a Quote Request a Sample

Mail Us: sales@incefiltration.com

Specifications

PARKER High Flow Filter Cartridges Description

PARKER high flow filter cartridge is a replacement cartridge for the depth filtration and other 2-1/2″ diameter cartridges for the high flow applications, such as reverse osmosis pre-filtration and similar applications that nominal efficiency can meet corresponding requirements. The flow rate of each filter cartridge is as high as 1300 liters per minute, which significantly reduce the number of filter cartridges and housing dimensions.

The treatment capacity of a PARKER filter cartridge is equivalent to that of 10 filter cartridges with an outer diameter of 2-1/2″ and a length of 40″.

Why Choose Ince’s PARKER High Flow Filter Cartridges

Ince’s PARKER High Flow Filter Cartridges accommodates up to 500 GPM with a compact design.
Consistent quality water is achieved by reducing particulate matter and removing chlorine.
Long-lasting and cost-effective, the cartridge has a long lifespan and requires fewer replacements.
Suitable for various applications, such as water purification, beverage processing, and pharmaceutical manufacturing.

PARKER High Flow Filter Cartridges Details

Axial Seal Design
End cap is designed with an axial seal to ensure a better verticality during installation and make the installation easy and fast.

Use High-quality Filter Media
The filter media is made of HEPA highly efficient low resistant materials are pleated to achieve up to 99% ultrahigh filtration
efficiency and extend the service life of filter cartridges.

Customized On Demand
Various types of non-standard filter elements can be customized according to different needs of customers.

PARKER High Flow Filter Cartridges Features:

1.High dirt holding capacity, longer service life.
2.Less cartridge changes out to save the labor cost.
3.O-ring design causes no bypass to ensure the filtration efficiency.
4.Easy handling results in less manpower.
5.Wide chemical compatibility for different applications.

PARKER High Flow Filter CartridgesApplications:

1.Seawater desalination
2.Machinery & equipment
3.Food & beverage
4.Power plant water treatment
5.Steel plant water treatment
6.Microelectronics
7.Oil & chemicals

PARKER High Flow Filter Cartridges Performance:

Maximum Operating Temperature	176°F (80°C) @ 30psid (2.1bar)
Maximum Differential Pressure	70psid (4.8bar) @ 77°F (25°C)
Maximum Differential Pressure	30psid (2.1bar) @ 176°F (80°C)
Suggested Maximum Flow Rate	100gpm
Liquid Flow Direction	Outside to inside

Search: Select from the options below to search our selection of PARKER High Flow Filter Cartridges. For questions or custom orders please Contact Us.

Disclaimer:

This information has been provided as a general guide. It is the customer's responsibility to select the proper container for product and application compatibility.
